Feature
|
Specification
| MODEL | MAX (KCAL/H) |
MAX fuel consumption (KG/H) |
MOTOR (KW) |
Turn-down-ratio | Power (V) |
Control system | Caliber (A) |
| FG-3 | 300,000 | 29.4 | 0.75 | 1:3 | 220/380 | HI-LOW Proportional control |
10 |
| FG-5 | 500,000 | 49 | 1.5 | 1:3 | 220/380 | HI-LOW Proportional control |
10 |
| FG-8 | 800,000 | 78.4 | 2.2 | 1:3 | 220/380 | HI-LOW Proportional control |
15 |
| FG-10 | 1,000,000 | 98 | 3.7 | 1:3 | 220/380 | HI-LOW Proportional control |
15 |
| FG-20 | 2,000,000 | 196 | 5.5(0.75) | 1:3 | 220/380 | HI-LOW Proportional control |
15 |
| FG-25 | 2,500,000 | 245 | 7.5(0.75) | 1:3 | 220/380 | HI-LOW Proportional control |
15 |
